Scania truck fault in the CAN communication with the chassis management system (CMS),this instruction show you guide on how to solve it.
Related Contents:
2025.04 Scania SDP3 V2.65.2 V2.40 Diagnostic Software Free Download
Scania VCI3 Diagnostic Adapter Full Chips
2025 2018 Scania Multi EPC Parts Catalogue Free Download
Error identification
A CAN message expected from the coordinator has failed to arrive.
Cause
Open circuit in voltage supply to CMS control unit.
The CMS control unit is not connected to the orange CAN bus.
The coordinator is not connected to the orange CAN bus.
Fault on the orange CAN bus.
Notes
–
Symptom
Reduced functionality for functions dependent on the CMS control unit.
Action
Check fault codes from the CMS control unit.
If no fault codes can be read from the CMS control unit:
Check the voltage supply and 15 voltage to the CMS control unit.
Check the CMS control unit connection to the orange CAN bus.
Check the coordinator connection to the orange CAN bus.
Check the orange CAN bus termination resistor, voltage and load. See Help > Communication fault for more information.
For more information about Scania truck,please refer to:Scania Trouble Repair.
